    Description

    Profiles for Inibuilds A400M. Supports dimming, test modes, and nearly all functions available on the WinWing.

    Other Airbus FCU+EFIS Packs:

    A320/330/Beluga Superpack

    A350 Pack

    Profiles include:

    • FCU Only
    • FCU+EFIS L&R
    • FCU+EFIS L
    • FCU+EFIS R

    Any issues? Let me know!

    Known limitations:

    • When MobiFlight is stopped, the test mode may be enabled for the annunciators.
    • Occasionally, the Dash mode will be disabled, and a figure will be displayed.
    • Some switches must be "initialized" before their in-sim positions match.
    • Right BARO may not display correctly when in Test mode.
    • ADF/VOR Selectors Currently Unused. (I am unsure if the A400M supports this functionality, I can update to support it later)
    • 320 Range mode is not used as the A400M only has five range modes
    • 'FPA Dial Scroll Down' does not work (A400M limitation; perhaps Inibuilds will fix it later)
    • Several autopilot modes and functions cannot be bound due to the limitations of switches and buttons.
    • TRK/FPA are bound to the same switch; I've added logic so that if you somehow get into TRK and V/S or HDG and FPA, clicking the button once will sync them back to the hardware mode. These cannot be displayed separately due to the limitation of the WinWing displays.

    Install MobiFlight 10.4.0.1+:

    To install MobiFlight 10.4.0.1+, download MobiFlight as regular. Once installed, select settings -> General -> Beta Versions -> Check the checkbox next to "Yes, I would like to receive beta version updates." Once done, restart MobiFlight.

    To Install:

    • First, ensure that you have MobiFlight 10.4.0.1+ installed.
    • Copy the associated profile that matches your hardware setup to where you store your MobiFlight profiles.
    • Open MobiFlight
    • Select File -> Open
    • Select the correct profile for your hardware setup
    • Load the sim and a supported aircraft.
    • Click Run on MobiFlight.
    • Ensure your aircraft is powered.

    Comments(13)

    Log in to join the discussion

    Log In

    5 months ago

    Hi.
    I am using MSFS2024 and MF v.10.5.3.18, but nothing happens when running the respective profile. The hardware (FCU1, EFIS L+R) is recognised but I cannot make any input. I have tried the A350 profile instead and this one is workingat least partly. What can I do to get your profile running?
    Thanks!

    about 1 year ago

    A fun fact: this profile also partially works for the iniBuilds A350. The FCU works, but unfortunately not the EFIS. :)
    gamesynsAuthor

    about 1 year ago

    Releasing a new profile shortly!

    about 1 year ago

    Thanks a lot for this! Works like a charm :)

    over 1 year ago

    Hey Gamesyns,

    Hitting ''Run'' gives me a bunch of red exclamation marks on the left hand side and the Sim status has a yellow warning icon, this one: ⚠️
    When checking it says ✅ MSFS Detected ⚠️ SimConnect OK. Wating for WASM Module. (MSFS)

    Would you have any idea what could be going on? My Mobiflight is BETA (10.4.0.3)
    gamesynsAuthor

    over 1 year ago

    It seems like your WASM module isn't installed in the community folder. I would ensure you have the program fully installed and correctly. They have a discord server if you can't troubleshoot it with that info, but that's a program side and not a profile side.

    over 1 year ago

    when i push the Alt knob in when i reach TOD it doesnt work,are you guys having the same issue?
    gamesynsAuthor

    over 1 year ago

    Does managed mode work on climb? If so, it's likely a bug with the aircraft. Try pushing in sim and letting me know if that works if it doesn't work when trying with the hardware first.

    over 1 year ago

    Hi my Wingwin combo activates but the lights are dim and when I turn the dials nothing happens. The displays stay static. Never mind :) finally got it to work, needed to add updates. Works fine. thanks so much. Now I can enjoy the A400M.

    over 1 year ago

    working knobs, but not displays. Thank you mate.
    gamesynsAuthor

    over 1 year ago

    Let me know if this latest update resolves this.

    over 1 year ago

    Once I run this profile, my FCU display goes dead, but I can still manipulate the knobs to change the values (SPD/ALT/HDG etc), and their respective values do indeed change in the sim, I just can't see the same inputs on my now dark display.

    Any ideas what might be causing this?
    gamesynsAuthor

    over 1 year ago

    Hmm that is very odd. I'll need to check in the latest update that they didn't modify a variable. Perhaps reach out to me on discord? @GameSyns
